Triplex Shark Jaw
Triplex Shark Jaw
Application: Triplex shark jaws has been installed for safe and secure handling of wire and chain and enable the connect or disconnect an anchor system in a safe way. They are mostly each installed at two sides pf vessels including the starboard side and the port side. It has two control panels in the aft part of the bridge console close to the winch operating panels. Before operating the plant, operators must read hand manuals for sure functions and instructions.
For more information, please kindly contact with us!
Features of Triplex Shark Jaw:
1. Having two separately retractable claws;
2. Applicable to anchor chains or steel wires;
3. The jaws falls to the same level with the deck;
4. Easy to disassemble the shackles;
5. Local or wheelhouse remote control panel;
6. Quick release system;
7. Electric/hydraulic drive;
8. Available accessories: hydraulic pump station, electrical box,control panel etc.
Specification:
1. S.W.L: 80~700tons
2. Working Power: 22KW;
3. Working Pressure:18MPa;
4. Chain Size: 40~114mm
5. Chain Breaking Load: 2940KN;
6. Wire Size: 15~100mm;
7. Surface: Smoothened with no burs or sharp edges;
8. Color: red, blue,gray or any other as you require;
9. Certificate:CCS, ABS,BV,DNV·GL,LR,RINA etc.
10. Application: for tug, anchor-handling and supply vessels.
Basic Technical Parameters for Your Reference:
Shark Jaw Model |
Towing Pin Model |
Bollard Pull(ton) |
Holding Capacity(ton) |
Power Required(kw) |
SJ-100 |
TP-100 |
40 |
100 |
15 |
SJ-200 |
TP-200 |
60 |
200 |
22 |
SJ-300 |
TP-300 |
85 |
300 |
22 |
SJ-400 |
TP-400 |
120 |
400 |
30 |
SJ-500 |
TP-500 |
150 |
500 |
30 |
SJ-700 |
TP-700 |
200 |
700 |
37 |
IACS Certificates:
