Marine A60 Fireproof Window

Marine A60 Fireproof Window

This product is a fireproof window and it's fire-resistant level is A60 ( In the one-hour standard fire resistant test, the temperature of the backfire side within 60 minutes doesn't increase more than 139 degrees from the original temperature, and at any point, the temperature including any joints doesn't exceed 180 degrees from the original temperature.), suitable for ship & offshore  where with A60 fireproof requirements. It can be made of steel and aluminum.

Drawing & Specifications:

no.	nominal size W*H*R		cutout in steel wall (W+52)*(H+52)*R1		glass outline side (mm) (W+40)*(h+40)*R3		glass thickness (T)
							E(t)+20+6=T	F(t)=20+6=7
1	355*500	R50	407*552	R76	390*540	R70	10+20+6=36	8+20+6=34
2	400*560		452*612		440*600		10+20+6=36	8+20+6=34
3	450*630	R100	502*652	R126	490*670	R120	10+20+6=36	8+20+6=34
4	900*630		952*682		940*670		12+20+6=38	10+20+6=36
5	1000*710		1052*762		1040*750		12+20+6=38	10+20+6=36
6	1200*800		1252*852		1240*840		15+20+6=41	12+20+6=38
7	1400*900		1452*952		1440*940		15+20+6=41	12+20+6=38
8	1600*900		1652*952		1640*940		19+20+6=45	15+20+6=41
9	1800*1000		1852*1052		1840*1040		19+20+6=45	15+20+6=41
10	2000*1000		2052*1052		2040*1040		19+20+6=45	15+20+6=41

IACS Certificate Approvals: BV, CCS, RMRS, IRS, RINA, DNV, GL, NK, LR, ABS

Product Pictures:
