VLH-53 Marine Direct Driving Air Compressor
VLH-53 Marine Direct Driving Air Compressor
Application
VLH-53 marine air compressor is a kind of medium pressure air cooling aire compressor,it is widely used for starting the engine of all kinds of ships.The displacement capacity is 45-74m3/h,the rotating speed is 1200-1800r/min.
Advantages Of HI-SEA VLH-53
Features
1.Reliable operation,low noise.
2.High efficiency,low exhaust temperature.
Technical Parameters
Compressor Model
VLH-53
Type
90vertical type, air-cooled type, two stage compression type
Cylinder Number
2
Rated Pressure (Mpa)
3.0
Rated Speed (r/min)
900
1000
1200
1500
Displacement Capacity (m3/h)
45
50
60
74
Oil Capacity (L)
6.8
Lubrication Method
gear pump pressure lubrication
Driving Mode
direct driving
Unloading Mode
manual or solenoid valve operation
Dimension (mm)
1250x860x840(direct driving)
1450x700x920(belt driving)
Engine Weight (kg)
~450
Certificates
The products approved by CCS,ABS,BV,DNV-GL,RINA,etc.
