RSN7-2000 Stud Welding Machine

RSN7-2000 Stud Welding Machine

1. Application

RSN7-2000 Stud Welding Machine is specially designed for generator power supply or power shortage. The construction site of the steel structure, which is often moved, needs to be transported by air and export trade. World-class key projects that require very strict welding quality.
2. Welding Material
The welding material is carbon steel, low alloy steel, stainless steel, copper and other materials with arc weldability. Apply welding on surfaces with an oxide layer, oil film, primer or electroplated workpiece. No deformation after welding, no bump mark. Horizontal welding, vertical welding, pitching welding, all-directional welding.
3. Features

- Thickness ≥ 3mm, welding M4 mm - M36 mm screw, special-shaped nails, corrugated nails, pin, heat preservation nail.
- IGBT inverter tehnology.
- Low price, less weight, power efficient, safe and reliable.

- Inner circuit board is under waterproof, anticorrosion, dampproof and dustproof treatment.

4. Technical Data

Item

RSN7-2000

Welding Range

Ø3mm~Ø24mm

Welding Current

200A~2000A

Welding Time

0.1S~3.0S

Welding Speed

Ø24 15pcs/minute

Input Power

AC 3~280V-440V

Rated Capacity

60KW

Power Switch

125A

Power Grade

lp23

Cooling Way

F

Dimension (L, W, H)

890mm×398mm×680mm

Weight

120kg

5. Standard Accessories

Standard Accessories of Arc Stud Welders

NO.

Accessories

Spec.

Qty.

1

Weld gun with 2m cable

TF-DH-25

1pc

2

Weld cable

120mm²

10m

3

Earth cable

120mm²

10m

4

chucks

Ø13,Ø16, Ø19, Ø22, Ø25

15pcs totally

5

Ferrule grips

Ø13,Ø16, Ø19, Ø22, Ø25

15pcs totally

6

Earth clamp

N/A

1pc

Note:

1. When ordering our arc stud welders, the above standard accessories are free of change.

2. Please inform us specifications and quantity of chucks and ferrule foot plate when ordering.

6. Certificate
