Marine Triangle Plate

Marine Triangle Plate

Description:

Marine triangle plate is steel plate that is used for marine mooring. Marine triangle plate’s surface is smooth and with no burs or sharp edges.

Overview:

Type: Marine Triangle Plate;

Material: Steel Plate, Stainless Steel;

Surface: Galvanized or Black Bituminous Paint;

Size: Can be customized;

Packing: Carton or Wooden Case;

Certificates: CCS, ABS, BV, LR, NK, RINA, etc..

Drawing of Marine Triangle Plate:

Parameters of Marine Triangle Plate:

Nominal Dia. of Anchor Chain Common Link d (mm)	D	L	R	T
50	73	195	108	65
52	75	203	112	68
54	78	211	116	70
56	81	218	120	73
58	84	226	125	75
60	87	234	129	78
62	90	242	133	81
64	93	250	138	83
66	96	257	142	86
68	99	265	146	88
70	102	273	151	91
73	106	285	157	95
76	110	296	163	99
78	113	304	168	101
81	117	316	174	105
84	122	328	181	109
87	126	339	187	113
90	131	351	194	117
92	133	359	198	120
95	138	371	204	124
97	141	378	209	126
100	145	390	215	130
102	148	398	219	133
105	152	410	226	137
107	155	417	230	139
111	161	433	239	144
114	165	445	245	148
117	170	456	252	152
120	174	468	258	156
122	177	476	262	159
124	180	484	267	161
127	184	495	273	165
130	189	507	280	169
132	191	515	284	172
137	199	534	295	178
142	206	554	305	185
152	220	593	327	198
157	228	612	338	204
162	235	632	348	211

Display of Stainless Steel Marine Triangle Plate(Customized Shape):
