Marine Intermediate Shafting Bearing


Marine Intermediate Shafting Bearing

Marine Intermediate Shafting Bearing




Application

The marine shafting intermediate bearing is designed and manufactured according to the GB/T14364-93 standard. It is widely used in export ship to increase support ability to shaft. This type of intermediate shafting bearing is recommended for small and medium vessels in inland water.

Advantages and Features

1. Compact structure, high quality;

2. Excellent performance, high security;

3. Working steadily and smoothly;

4. Easy installation, easy maintenance;

5. Corrosion resistance, long lifespan;

6. Reliable service, exquisite appearance;

7. Can be customized according to your requirements.

Drawing of Product



Main Dimensions and Parameters

1. Velocity: 1.5-8m/s

2. Unit Pressure: ≤1.6MPa

3. Slide Oil Temperature: 65

4. Cooling Water Capacity: 0.5-7T/h

Type Model D(mm) Design Parameters
A single-oil-wedge slipping type with upper bearing 800-220 as a medium and small-sized ship intermediate bearing which is near the tail piper or load pressure
B multis-ol-wedge slipping type 250-800 as a big-sized ship shafting intermediate bearing
C single-oil-wedge slipping type with upper bearing 250-800 as a big-sized ship inetemediate bearing which is near the tail pipe or with load pressure

Certificates

The products approved by CCS, BV, ABS, RINA, NK, DNV-GL,etc.
