Marine Electrical Bow Thruster

Marine Electrical Bow Thruster

Application
On the basic of design concept of reliability, high efficiency and endurance, The electrical motor has the form of a thin ring. Its stator is incorporated in the tunnel and its rotor carries propeller blades. Waterflow through the unit is unobstructed since there is no gearbox in the tunnel, nor are struts needed to support a hub. Together these factors give a high total efficiency and reduced noise and vibration. According to the different type of propeller, It can be installed vertically or horizontally.

Tunnel thruster are particularly useful when maneuvering in ports, shallow and coastal waters and waterways. The use of tunnel thruster shorten the time of maneuvering and reduce costs of to-wage. Tunnel thrusters are particularly useful when manoeuvring in ports, shallow and coastal waters and waterways. The use of tunnel thrusters shorten the time of manoeuvring and reduce costs of towage.

Features
1.Optimized combination of diameter-rotate speed of propeller, that improve propulsion efficiency; In the same thrust force we have smaller diameter, improve the ratio of utilization of cabin.
2.Skew blade and large disk ratio, reduce vibration and improve cavitation performance.
3.Gear and bearing have high strength and long longevity, and dipped into oil to got better lubrication and cooling effect, which improving the reliability of TP.
4.Underwater structure are optimized so that it have rational construction, which convenient for maintenance and repairing.
5.Tail shaft sealing are enough reliable sealing, meet the strict requirements of anti-pollution law of sea and ocean environment.
6.For extreme load conditions.
7.Low noise and vibration, installed vertically or horizontally, suitable for Transportation vessel, tugboat, ocean engineering vessel, ro/ro ship, cargo liner.
8.We can design and manufacture the product according to client's drawing or sample.


Technical Parameters


CTT010 CTT060 CTT160 CTT550 CTT1010
Min-1 1470 1170 1470 1170 1470 1170 1470 1170 1170 970
Hz 50 60 50 60 50 60 50 60 60 50
KW/h.p. 63/86 50/68 125/170 100/136 280/380 280/380 900/1224 725/986 1250/1700 1000/1360
KN 9.5 7.9 17.5 14.5 42 42 125 110 183 155
mm 1000 1000 1500 2000 2500
mm 12 12 20 20 20
mm 500 630 1000/1100 1750 2100
Kg 300 430 1450 2680 3200

Propeller Dia. Input power max. Frequency Input rpm Zero pitch  torque max
rotating inertia weight
Φ.mm KW HZ rpm NM Kgm2 tunnel device Motor&starter
1100 320 50 1450 160 1.2 1300 850
380 60 1750 220
1300 445 50 1450 340 1.9 2500 1300
480 60 1750 470
1650 590 50 1450 340 4.5 3700 2300
800 60 1750 500
2800 2240 50 980 3935 65 20500 5000
2010 60 880 3300
2300 3500 50 590 5600 358 31000 6000
3500 60 590 5600
Certificates
