1. Marine Black And Gray Water Processor Preface:

This marine black and gray water processor is applicable to treat the sewage, which means human body wastes and the wastes from the toilets on vessels , to meet the effluent standards of IMO MEPC.159（55), and discharge the effluent to overboard. It is also applicable to treat galley & shower drainage which is called “grey water” on condition that the “grey water” should be pretreated or should select a bigger capacity model to match with.

The processor belongs to the key devices for prevention of pollution form ships in seas and oceans according to the revised Annex IV of the International Convention of the Prevention of Pollution (MARPOL 73/78). The MEPC.2 (VI) resolution adopted on 3th, December,1976 is the present guidelines on implementation of effluent standards and performance tests for STP, which is called “old standards”. This device is according to the MEPC.159(55) resolution acted on 13 October 2006, which is called “new standards”. The convention (MARPOL 73/78)provides that all STPs installed on board on or after 1 January 2010 should meet the MEPC.159(55)resolution.

The SWCM type Ships Waste Water Treatment uses activated sludge, contact oxidizing and principle of biologic membrane to digest the organic pollutant, which can treat sewage effectively and reach at the IMO new effluent standard or other stricter requirements.

Equipment list

No.	Name	Amount	Remarks
1	Main body (includes aeration tank, contact oxidation tank, settling tank, membrane tank)	1set	Channel Steel
2	Cutting pump	1set	Assembly
3	Air pump	2sets	Assembly
4	Discharge pump	1set	Assembly
5	UV disinfectant	1set	Assembly
6	Membrane module	1set	Assembly
7	Electric control box	1set	Assembly
8	Piping accessory of device	1set	Assembly

Comparison Differences

Crushing discharge pump

Brand	Foreign Famous brand	Domestic Brand
Pro& Cons	Long service life, stable operation and high processing efficiency.	The pump body is fragile, the service life is short, easy to damage, and the work is unstable.

Air pump(The air pump is composed of the main engine, air bag, base, lubrication, cooling and other components. The main components of the main engine are composed of main parts such as pump body, rotor and sliding vane.)

Brand	Foreign Famous brand	Domestic Brand
Pro& Cons	Long service life, stable operation and high processing efficiency.	The pump body is fragile, the service life is short, easy to damage, and the work is unstable.

MBR Membrane

Brand	Foreign Famous brand	Domestic Brand
Pro& Cons	Long service life, lower replacement costs	Short service life and high replacement cost

Disinfection device

Brand	UV	Medicine
Pro& Cons	Environmentally friendly, efficient, safe to operate, and does not produce harmful chemicals. However, the power consumption is large, and the UV lamp needs to be replaced regularly.	Economical and effective, with follow-up disinfection effect. But it is ineffective for some virus spores, produces odor, is affected by pH, and has disinfection by-products

Main Products

Marine Black and Gray Water Processor
20 Persons Sewage Treatment Device	25 Persons Wastewater Treatment Device	30 Persons Waste Water Treatment Device	40 Persons Sewage Treatment Plant Manufacturer
50 Persons Waste Water Treatment Plant Manufacturer	60 Persons Wastewater Treatment Plant Manufacturer	80 Persons Sewage Treatment Equipment Manufacturer	100 Persons Waste Water Treatment Equipment Manufacturer
120 Persons Wastewater Treatment Equipment Manufacturer	150 Persons Sewage Treater Manufacturer	200 Persons Waste Water Treater Manufacturer	250 Persons Wastewater Treater Manufacturer
300 Persons Sewage Processer Manufacturer		400 Persons Wastewater Treatment Equipment Factory

2. Marine Black And Gray Water Processor Models and MainTechnical Parameters:

Model	SWCM（E）
	15	20	25	30	40	50	60	80	100	120	150	200	250	300	400
Average load (L/d)	1190	1540	1890	2310	3080	3780	4480	6020	7700	9100	11200	14700	18200	23100	30800
Peak load (L/h)	149	193	237	289	385	473	560	753	963	1138	1400	1838	2275	2888	3850
Organic load (kgBOD5/d)	0.595	0.77	0.945	1.155	1.54	1.89	2.24	3.01	3.85	4.55	5. 6	7.35	9.10	11.55	15.4
Rated Capacity (persons)	15	20	25	30	40	50	60	80	100	120	150	200	250	300	400
Max capacity (persons)	17	22	27	33	44	54	64	86	110	130	160	210	260	330	440
Electricity	AC 380V/50Hz/3φ, AC 415V/50Hz/3φ, AC 440, 60Hz/3φ, etc.
Power (kW)	2.5	2.5	2.5	2.5	3.0	3.0	3.5	4.0	4.0	4.0	6.0	6.0	7.0	9.0	11
Outline Size (mm) L×W×H	1870 × 1200 × 1450	1680 × 1400 × 1570	1890 × 1400 × 1560	1980 × 1500 × 1650	2320 × 1600 × 1700	2320 × 1700 × 1880	2650 × 1700 × 1860	2800 × 1900 × 2090	2800 × 2100 × 2300	3030 × 2100 × 2300	3090 × 2250 × 2390	3640 × 2250 × 2390	3890 × 2450 × 2580	4790 × 2450 × 2600	5980 × 2450 × 2600
Dry weigh (kgs)	1000	1000	1100	1200	1300	1450	1600	1850	2200	2300	2800	3000	3300	3700	4200
Wet weight (kgs)	2283	2640	2740	3500	4400	5073	5270	6517	8268	9166	11340	13267	16538	20357	25417
Effluent standard	BOD5≤25 Qi/Qe mg/L, COD≤125Qi/Qe mg/L, TSS≤35 Qi/Qe mg/L, coliform≤100/100ml, PH6～8.5, CL2≤0.5mg/L

3. Marine Black And Gray Water Processor Advantages:

(1) Adopting horizontal circular design, ellipse closures on both ends, pressure resistance and compact structure.
(2)The device is adopted auto-control, and compliance with the requirement of 24-hours unattended cabin.
(3)Adopting the 'MBR' technology, allow devices to narrow the size, and solve the conflict of small space of cabin, but big volume of device.
(4) The intermittent aeration in bio-membrane tank and hollow fiber membrane tank, form the process of 'aerobic - anoxic', and resolve the problem of 'nitrogen and phosphorus removal'.
(5) The device is adopting the principle of air-lifting to transfer the sludge from sediment tank and membrane tank to aeration tank, mealtimes the pump stops and air never stopped, so as the scale on the membrane surface comes down. Due to back flushing and clean the membrane online USD technology patent, so the life of membrane can be prolonged at least 8 to 9years.
(6) "On-line" cleaning technology, making the dirt on membrane off automatically, recover membrane flux. It can be solved the problem of opening the cleaning or replacement of membrane difficultly caused by the small space in cabin.
(7) The effluent after further treatment can be reached at the requirement of water reuse.

Marine Black and Gray Water Processor Maintenance please click here.

4. Picture of Marine Black and Gray Water Processor

5. Several Class Certificates Supply:

ABS, BV, DNV.GL, LR, RINA, NK, USCG, and CCS class certificates.
