Introduction:

Japan stock anchor is a kind of stock anchor, which it is also called JIS stock anchor. All our anchors are approved by the Classification Societies.

The anchor shank and anchor head of the Japan stock anchor are cast in one part. Although it has a large grab-to-weight ratio and is not easy to turn over, it is suitable for small boats and sailboats, because it is easy to scratch the bottom of the big boat in shallow water.

These anchors are designed to be a reliable and cost-effective solution for anchoring in a variety of sea conditions. The exact type of ship that a JIS stock anchor is applicable for will depend on various factors such as the size of the ship, the operating conditions, and the local regulations. It is always best to consult with a maritime expert or the anchor manufacturer for specific recommendations for a given ship type.

Drawing of Japan Stock Anchor:


Main Model of Japan Stock Anchor:

Nominal Weight

(kg)

Size(mm)

H

L

B

500

2000

2065

1350

700

2260

2335

1510

750

2310

2342

1560

1000

2550

2637

1700

1500

2890

2960

1950

2000

3160

3272

2140

3000

3630

3555

2650

3500

3810

3820

2570

4000

4000

4135

2920

5000

4310

4470

3140

6000

4580

4740

3330

7000

4820

4980

3530

8000

5040

5215

3620

Features:

Type: Stock Anchor;

Main Material: ZG200-400C cast steel;

Nominal Weight: 500kg to 8000kg;

Finish: black painted, hot dip galvanzied or customized;

Packing: nude/pallet/plywood case or others;

Certificates: CCS, ABS, BV, LR, NK, RINA, etc.

For Introduction of Cast Steel Anchor Production Process Please Check the Link Below:

http://www.cqhisea.com/newsshow.php?cid=4&id=99

Japan Stock Anchor Ready to Ship:

Anchor Maintenance:

1) When lifting the anchor, wash off the sediment and debris on the anchor, and the damaged paint needs to be polished and repainted;

2) Observe whether the cross pin of the anchor shackle is loose. If it is loose, it should be reinforced or replaced in time.

3) According to the frequency of use, the anchor chain should also be checked regularly, all the anchor chains should be arranged on the deck, sand off damaged paint and rust, and each chain link should be carefully checked and maintained to avoid anchor loss due to anchor chain breakage.
