German Standard Anchor Chain Releaser

German Standard Anchor Chain Releaser

Application:

German standard anchor chain releaser is easy for users to operate on the marine deck. Anchor chain releaser is installed outside of the storage bulkhead, which makes it convenient for users not to go to the the chain storage to cut off the anchor chains. Besides, it can guarantee ships and persons’ safety. We can also supply customized products of this type according to your requirements.

Features of German Standard Anchor Chain Releaser:

1. Standard: German Standard;

2. Applicable Chain Dia.: 36mm to 152mm;

3. Material: Cast Steel;

4. Surface treatment: Anti-rust Paint Surface;

5. Customized size is available;

6. Certiicates: CCS, ABS, DNV·LR, NK, ect..

Drawing of German Standard Anchor Chain Releaser:

Parameters of German Standard Anchor Chain Releaser:

Anchor Chain Dia. (mm)	Φd1×s1	Φd2	l1	u1	v1	v2
36-46	273×12.5	375	735	75	10	75
48-56	323.9×14.2	440	835	95	12	90
58-68	406.4×16	540	995	110	14	95
70-81	508×17.5	645	1245	105	15	100
84-92	508×17.5	645	1245	130	15	150
95-105	610×20	754	1430	130	18	150
107-114	610×20	754	1430	170	18	185
117-127	711×22.2	856	1615	170	20	185
130-137	813×22.2	958	1790	170	20	185
142-152	914×25	1060	1970	190	22	200
