GB T597 Marine Bronze Male Thread Check Valve

GB T597 Marine Bronze Male Thread Check Valve

1. Application

GB T597 Marine Bronze Male Thread Check Valve can be used in sea water, fresh water, lubricanting oil, fuel oil and steam with a temperature of less than 250 degrees. Most of the time, it can be used to repair ships and shipbuilding.

2. Material

(1) body: cast aluminum bronze

(2) cover & disc: aluminum bronze

The materials mentioned before are basic materials, ship-owners can choose better materials.

3. Nominal Pressure(KPa) & Diameter(mm)

Pressure: 4.0

Diameter: 10~32

4. Features

(1) Excellent quality and reasonable price.

(2) We can provide sample if necessary.

(3) We can provide IACS certificate such CCS, ABS, BV etc.

5. Dimensions

DN

(mm)

Structure dimension

Thread joint

Wrench size

Lift

Range

m

Weight(kg)

L

H

H1

S2

A

B

A

B

D

D1

D2

I

I1

A

B

A

B

10

94

47

54

20

41

M27*1.5

24.8

14

16

3

27

32

7

0.61

0.58

15

110

55

61

25

52

M36*2

33.0

22

22

5

32

41

10

1.00

0.94

20

116

58

65

32

55

M39*2

36.0

25

23

5

36

46

12

1.19

1.04

25

130

65

70

38

64

M48*2

45.0

32

26

6

46

50

14

1.71

1.58

32

140

70

84

46

72

M56*2

53.0

38

28

6

46

60

16

2.87

2.61


6. IACS Certification: DNV, BV, ABS, CCS, LR, NK, KR, RINA.
