GB T596 Marine Bronze Male Thread Stop Check Valve

GB T596 Marine Bronze Male Thread Stop Check Valve

1. Application

GB T596 Marine Bronze Male Thread Stop Check Valve can be generally used to repair ships, and it can be used in sea water, fresh water, lubricanting oil, fuel oil and steam with a temperature of less than 400 degrees.

2. Material

(1) body: cast aluminum bronze

(2) cover & disc & stem: aluminum bronze

To meet the different needs of customers, the special materials can be customized according to one's request processing.

3. Nominal Pressure(KPa) & Diameter(mm)

Pressure: 4.0

Diameter: 10~32

4. Features

(1) Excellent quality and beautiful shape.

(2) We can provide sample if necessary.

5. Dimensions

DN

(mm)

Structure dimension

Thread joint

Wrench size

Hand wheel

Lift

Range

m

Weight(kg)

L

H

H1

S2

A

B

A

B

D

D1

D2

I

I1

A

B

D0

S1

A

B

10

94

47

128

20

41

M27*1.5

24.8

14

16

3

27

32

80

8

7

0.98

0.95

15

110

55

143

25

54

M36*2

33

22

22

5

32

41

80

8

10

1.51

1.45

20

116

58

154

32

55

M39*2

36

25

23

5

36

46

100

9

12

1.80

1.75

25

130

65

167

38

64

M48*2

45

32

26

6

46

50

120

11

14

2.51

2.34

31

140

70

198

46

72

M56*2

53

38

28

6

46

60

140

12

16

4.22

3.97


6. IACS Certificate: DNV, ABS, BV, CCS, LR, NK, KR, RINA.
