Double Flat Glass Level Gauge

Double Flat Glass Level Gauge


Double Flat Glass Level Gauge

1. General
The level can be indicated clearly because of the double color indication of the level gauge. And because of good functioning of the lower self-closing valve, when required, the liquid chambers can be changed without drain of the tank. It is easy to operate, and safe for use. The level gauge applies to measure height for water, lubricating oil and of flash point over 65℃.

2. Main technical parameter

Working pressure

0.2MPa

Test pressure

0.5MPa

Main material

Body: Q235A OR 1Crl8Ni9Ti

Self-closing valve: ZQSnl0-2

3. Measuring range


Structure type

A,B,C,D type

A,B,C,D type

Nominal length

360

650

1520

1810

2100

2390

2680

2970

3260

3550

3840

940

1230

4130

4420

4710

5000

5290

5580

5870

6160

6450

Remark

——

If A type is selected, the upper self-closing valve is open normally

4. IACS Certificate: ABS, DNV-GL, LR, RINA, BV, CCS.
