Double Braided Marine Mooring Rope

Double Braided Marine Mooring Rope

Application:

Double braiding is a braiding method that uses inner and outer braiding to improve the performance of the marine ropes. The inner and outer layers of the double braided marine mooring ropes can be made of different materials to achieve different effects.

For example, the inner polypropylene filament of the double braided marine mooring rope is mainly to bear the effect of tension, and the outer polyester cover can greatly increase the abrasion resistance of the double braided marine mooring ropes.

Construction of Double Braided Marine Mooring Rope:

Main Performance of Materials for Double Braided Marine Mooring Rope:

Specification		PA multifilament		Polyester		PP multifilament		Polyester/PA		Polyester/PP		Polyamide/PP
Dia. (mm)	Cir. (inch)	Ktex	KN	Ktex	KN	Ktex	KN	Ktex	KN	Ktex	KN	Ktex	KN
4	1/2	10.3	3.7	12.2	3.2	8.4	2.4	12.0	4.0	9.0	2.6	8.5	2.7
6	3/4	23	8.3	27.4	7.2	18.8	5.4	27.0	9.0	20.2	5.8	19	6.0
8	1	41	15	49	13	33	9.6	48	16	36	10	34	11
10	1-1/4	64	23	76	20	52	15	75	25	56	16	53	17
12	1-1/2	92	33	109	29	75	22	108	35	81	23	76	25
14	1-3/4	126	45	149	39	102	29	147	47	110	31	104	33
16	2	164	59	195	51	133	38	192	62	143	41	136	44
18	2-1/4	207	75	246	65	168	49	243	78	181	52	172	55
20	2-1/2	255	92	304	80	208	60	300	96	224	64	212	68
22	2-3/4	309	111	368	97	252	73	363	116	271	77	256	82
24	3	368	127	440	114	299	86	430	138	325	93	304	98
28	3-1/2	501	172	597	157	404	118	585	182	430	124	415	130
32	4	654	225	779	205	528	154	760	236	576	162	542	170
36	4-1/2	828	285	998	262	668	195	970	314	732	216	679	227
40	5	1018	352	1220	324	825	240	1180	385	902	266	838	280
44	5-1/2	1236	420	1470	378	1006	294	1440	462	1093	324	1030	341
48	6	1473	500	1760	450	1190	354	1710	546	1300	380	1230	400
52	6-1/2	1730	600	2050	535	1390	411	2010	635	1525	443	1440	466
56	7	2009	690	2380	621	1610	474	2330	731	1773	513	1670	540
60	7-1/2	2297	780	2740	712	1850	539	2670	834	2035	584	1910	615
64	8	2616	900	3120	810	2090	613	3050	942	2310	665	2170	700
72	9	3306	1090	3950	980	2640	767	3860	1180	2924	846	2730	890
80	10	4089	1344	4870	1240	3290	934	4860	1442	3610	1036	3350	1090
88	11	4954	1626	5910	1500	3950	1117	5780	1729	4371	1254	4060	1320
96	12	5892	1950	7020	1750	4710	1304	6870	2033	5207	1501	4880	1580
104	13	6911	2320	8250	2090	5480	1513	8070	2402	6112	1758	5800	1850
112	14	8024	2670	9560	2400	6390	1694	9360	2730	7082	2043	6710	2150
120	15	9198	3050	10970	2750	7350	2010	10740	3100	8127	2328	7690	2450

Double Braided Marine Mooring Rope with Soft Eye:
