CBM 1052-81 Cast Steel Stop Check Valve

CBM 1052-81 Cast Steel Stop Check Valve

1. Application

CBM 1052-81 Cast Steel Stop Check Valve main function is to prevent the backflow of the medium, to prevent the pump and drive motor reversal, and the release of the container medium.

2. Material

(1) body & cover: ZG230-450

(2) disc: 25

(3) stem: 2Cr13

The material of this product can be made to order, for example:cast steel, stainless steel 304, stainless steel 316L etc.

3. Technical Data

(1) nominal pressure(MPa): 2.0

(2) nominal diameter(mm): 32~150

4. Features

(1) We have IACS Certificate such as CCS, ABS, LR etc.

(2) Strict quality control to ensure product quality.

5. Dimensions

DN

(mm)

Structure dimension

flange

L

H

D

C

g

h

t

A

B

A

B

32

190

100

236

301

135

100

80

19

18

40

200

110

260

325

140

105

85

50

230

125

288

383

155

120

100

65

270

135

335

436

175

140

120

20

80

300

150

366

475

200

160

135

23

22

100

350

170

427

548

225

185

160

24

125

430

200

493

633

270

225

195

25

26

150

500

225

556

709

305

260

230

28

6. IACS Certificate: RINA, NK, LR, BV, KR, DNV, CCS, ABS.
