Boat Wire Mesh Door

Boat Wire Mesh Door

Boat Wire Mesh Door is adopted for working cabin or used together with weathertight door. It is made of steel. There are three types: round corner, square corner and double leaves. Customization is available. This door is produced in accordance with the standard of CB*452-81. We supply variety of marine doors and other marine outfitting equipment. Welcome to contact us for more information.

Drawing:

Specification:

type	nominal size B*L	Door size B1*L1	cutout in steel wall B2*L2	R	Weight Kg	Application
A	600*1400	592*1392	640*1440	100	42	Cooperate with weathertight door
	700*1400	692*1392	740*1440		47.2
	600*1600	592*1592	640*1640		44.2
	700*1600	692*1592	740*1640		44
	800*1600	792*1592	840*1640		49
B	600*1600	592*1592	640*1640	-	43	working cabin
	700*1600	692*1592	740*1640		46
	800*1600	792*1592	840*1640		48
C	1000*1600	2(492*1592)	1040*1640		65
	1200*1600	2(592*1592)	1240*1640		69.9
	1400*1600	2(692*1592)	1440*1640		72

Optional Certificates: CCS, BV, LR, DNV.GL, ABS, NK, RINA, IRS, RMRS

Product Figure:
