Aluminum Cabin Sliding Door

Aluminum Cabin Sliding Door

Introduction

Aluminum cabin sliding door is used to the cabin inside ship superstructure. The door surface is oxided or covered by PVC. The row material can be stainless steel or aluminium. There are four types of this door: base mode, with fixed light, with ventilator escaping exit, and with fixed ventilator escaping exit. It is single-leaf and can be left-open or right-open. The quality of our products are excellent, in accordance with the ISO standard. Welcome to contact us to get detailed information if you are interested in our products.

Drawing:

/uploads/image/20180930/Sliding Door for Cabin.jpg

Specification:

type size of doorway frame size cutout in steel wall size of door B3*L3 Depth opening

weight

kg

B*L B1*L1 B2*L2 D ≥76 aluminum stainless steel
A B C D A B C D
single leaf A 600*1200 600*1200 600*1200 600*1200 T1+T2+35 L 29 31 31 33 75 77 77 79
650*1400 650*1400 650*1400 650*1400 31 33 33 35 81 83 83 85
B 650*1600 650*1600 650*1600 650*1600 33 35 35 37 86 88 88 90
700*1600 700*1600 700*1600 700*1600 36 38 38 40 94 96 96 98
C 600*1200 600*1200 600*1200 600*1200 R 57 61 61 65 148 152 152 156
650*1400 650*1400 650*1400 650*1400 61 65 65 69 159 163 163 167
D 650*1600 650*1600 650*1600 650*1600 65 69 69 73 169 173 173 177
700*1600 700*1600 700*1600 700*1600 71 75 75 79 185 185 185 193


Optional IACS Certificates: CCS, LR, DNV.GL, ABS, NK, BV, RINA, IRS, RMRS

Product Displaying:

/uploads/image/20180925/Marine Stainless Steel Gastight Sliding Door.jpg
