AC-14 Fully Balanced HHP Anchor

AC-14 Fully Balanced HHP Anchor

Application:

AC-14 fully balanced HHP anchor is an updated anchor of stockless anchor. The crown of AC-14 fully balanced HHP anchor is very wide and the anchor claw is thick and long. This anchor has the characteristics of high grab-to-weight ratio and strong stability, and is often used as a bower anchor for large ships. AC-14 fully balanced HHP anchor can be applied to various seabed conditions, and it is widely used on large ships.

Details:

Type: Fully Balanced HHP Anchor;

Material: ZG230-450 Cast Steel;

Nominal Weight: 75kg to 100000kg;

Finish: Bituminous paint;

Packing: Carton, Plywood Case, Plywood Pallet or Nude Packing;

Certificates: CCS, ABS, BV, LR, NK, RINA,etc.

Drawing of AC-14 Fully Balanced HHP Anchor:


Main Model of AC-14 Fully Balanced HHP Anchor:

NOMINAL WEIGHT

(KG)

A

(mm)

B

(mm)

C

(mm)

D

(mm)

E

(mm)

F

(mm)

G

(mm)

J

(mm)

75

550

326

350

606

188

185

115

24

100

607

380

385

704

207

200

130

28

120

635

380

402

704

217

215

145

32

180

742

442

470

822

254

252

160

36

225

828

495

525

915

283

277

175

40

250

828

495

525

915

283

280

192

40

300

882

525

559

975

301

298

192

45

340

918

548

582

1015

313

310

215

48

360

918

548

582

1015

313

313

215

48

430

990

590

628

1098

339

336

215

48

495

1025

610

650

1135

350

348

235

50

585

1102

658

699

1220

376

375

235

50

675

1152

690

731

1278

394

390

255

60

765

1205

718

764

1335

411

408

255

60

855

1250

745

793

1385

427

420

280

62

970

1300

775

826

1445

444

440

280

62

1080

1350

805

855

1495

461

455

280

62

1200

1400

835

887

1545

478

470

310

68

1305

1440

858

913

1595

492

485

310

68

1440

1486

885

943

1645

507

505

310

68

1575

1534

915

972

1695

523

518

340

74

1710

1575

940

998

1745

538

532

340

74

1845

1616

965

1025

1785

552

546

340

74

1980

1650

985

1048

1830

564

560

380

82

2100

1686

1005

1070

1865

575

570

380

82

2295

1738

1035

1102

1920

593

588

380

82

2475

1780

1062

1128

1970

607

602

385

82

2655

1820

1085

1155

2018

621

615

385

82

2835

1862

1109

1180

2057

635

625

410

90

3040

1896

1130

1204

2100

646

640

410

90

3550

2030

1198

1287

2225

693

680

415

100

3940

2080

1240

1318

2300

709

705

450

100

4500

2170

1295

1376

2405

741

735

450

100

4840

2225

1330

1410

2465

760

755

480

110

5175

2275

1358

1443

2520

777

770

480

110

5610

2339

1396

1483

2590

798

790

500

110

6000

2390

1426

1515

2646

816

810

500

110

6225

2420

1443

1534

2678

826

820

540

117

6525

2450

1462

1554

2712

836

830

540

117

6975

2507

1496

1589

2775

855

848

580

121

7350

2560

1526

1622

2832

873

866

580

121

7875

2610

1558

1655

2890

891

884

600

130

8325

2665

1590

1689

2950

909

902

600

130

8775

2707

1614

1715

2996

924

916

630

135

9300

2765

1652

1754

3064

945

936

640

140

9675

2805

1674

1778

3104

957

948

640

140

10125

2850

1700

1806

3152

972

960

640

140

10575

2880

1720

1827

3192

984

976

660

145

11025

2930

1750

1859

3247

1001

990

660

145

11700

2987

1782

1894

3308

1019

1010

700

155

12075

3010

1800

1906

3343

1027

1020

700

155

12675

3065

1812

1945

3364

1047

1028

700

155

13350

3132

1870

1986

3470

1069

1060

700

155

14100

3178

1896

2015

3520

1084

1076

730

160

14700

3228

1924

2045

3570

1099

1090

730

160

15400

3272

1954

2075

3626

1117

1108

770

170

16100

3320

1980

2110

3680

1132

1125

770

170

16900

3350

2000

2126

3720

1144

1144

770

170

17250

3380

2016

2142

3740

1151

1144

770

170

17800

3440

2050

2180

3806

1173

1162

800

180

18800

3500

2088

2220

3875

1193

1185

800

180

20000

3573

2132

2265

3956

1220

1210

820

185

25000

4100

2437

2600

4577

1399

1375

880

200

30000

4358

2888

2765

4663

1484

1380

940

210

35000

4588

3040

2910

4910

1560

1453

940

210

40000

4794

3177

3041

5129

1632

1518

960

220

45000

4988

3304

3163

5334

1698

1579

1015

225

50000

5164

3422

3276

5526

1758

1635

1050

230

55000

5330

3532

3382

5703

1815

1688

1080

240

60000

5490

3639

3483

5875

1870

1739

1136

250

65000

5639

3737

3578

6033

1920

1785

1156

255

70000

5778

3829

3666

6183

1968

1830

1188

260

75000

5914

3919

3752

6328

2014

1873

1210

265

80000

6044

4005

3835

6468

2058

1914

1235

270

85000

6166

4086

3912

6598

2100

1953

1258

280

90000

6284

4164

3987

6724

2140

1990

1258

280

95000

6398

4240

4059

6845

2178

2025

1300

285

100000

6506

4312

4128

6962

2216

2060

1403

310

For Introduction of Cast Steel Anchor Production Process Please Check the Link Below:

http://www.cqhisea.com/newsshow.php?cid=4&id=99

AC-14 Fully Balanced HHP Anchor after Painted:
