70mm U3 Stud Link Anchor Chain
70mm U3 Stud Link Anchor Chain
Application: Hi-sea Marine supply all kinds of marine anchor chains with ABS, BV, DNV·GL, NK,LR,KR, RINA, CCS approvals. Marine welded stud link anchor chain has been widely used because of its simple process, low cost and good quality. Each shackle is 27.5 meters in length and every two sections are connected by a chain ring or shackle.
Product Detail
1.Material: Forged steel
2.Diameter: 12.5mm to 162mm
3.Finish: Black painted or hot dip galvanized
4.Marine Certificate: CCS, ABS, LR, NK, RS, DNV·GL, KR, BV, RINA
5.Grade: U2, U3, RQ3/NVR3, RQ3S/NVR3S, RQ4/NVR4
6.Length: 27.5m
Reasons for Choosing Hi-Sea Marine:
1. Experienced, Reputable Supplier;
2. Supply a Large Range of Marine Equipment;
3. High Quality Products;
4. Reasonable and Competitive Price;
5. Short Delivery;
6. Excellent One-Stop Service;
7. Meet All the Requirements of Customers;
8. Supply ABS, CCS, BV, NK or other Certificates as Required.
Drawing of 70mm U3 Stud Link Anchor Chain:
Diameter |
U2 |
U3 |
U2 |
U3 |
Approx. mass |
mm |
kN |
kN |
kN |
kN |
kg |
12.5 |
66 |
92 |
92 |
132 |
98 |
14 |
82 |
116 |
116 |
165 |
122 |
16 |
107 |
150 |
150 |
216 |
161 |
17.5 |
127 |
179 |
179 |
256 |
193 |
19 |
150 |
211 |
211 |
301 |
227 |
20.5 |
175 |
244 |
244 |
349 |
264 |
22 |
200 |
280 |
280 |
401 |
305 |
24 |
237 |
332 |
332 |
476 |
362 |
26 |
278 |
389 |
389 |
556 |
425 |
28 |
321 |
449 |
449 |
642 |
493 |
30 |
368 |
514 |
514 |
735 |
566 |
32 |
417 |
583 |
583 |
833 |
644 |
34 |
468 |
655 |
655 |
937 |
727 |
36 |
523 |
732 |
732 |
1050 |
815 |
38 |
581 |
812 |
812 |
1160 |
909 |
40 |
640 |
896 |
896 |
1280 |
1007 |
42 |
703 |
981 |
981 |
1400 |
1110 |
44 |
769 |
1080 |
1080 |
1540 |
1218 |
46 |
837 |
1170 |
1170 |
1680 |
1331 |
48 |
908 |
1270 |
1270 |
1810 |
1450 |
50 |
981 |
1370 |
1370 |
1960 |
1573 |
52 |
1060 |
1480 |
1480 |
2110 |
1701 |
54 |
1140 |
1590 |
1590 |
2270 |
1835 |
56 |
1220 |
1710 |
1710 |
2430 |
1973 |
58 |
1290 |
1810 |
1810 |
2600 |
2117 |
60 |
1380 |
1940 |
1940 |
2770 |
2265 |
62 |
1470 |
2060 |
2060 |
2940 |
2419 |
64 |
1560 |
2190 |
2190 |
3130 |
2577 |
66 |
1660 |
2310 |
2310 |
3300 |
2741 |
68 |
1750 |
2450 |
2450 |
3500 |
2909 |
70 |
1840 |
2580 |
2580 |
3690 |
3080 |
73 |
1990 |
2790 |
2790 |
3990 |
3353 |
76 |
2150 |
3010 |
3010 |
4300 |
3634 |
78 |
2260 |
3160 |
3160 |
4500 |
3828 |
81 |
2410 |
3380 |
3380 |
4820 |
4128 |
84 |
2580 |
3610 |
3610 |
5160 |
4440 |
87 |
2750 |
3850 |
3850 |
5500 |
1762 |
90 |
2920 |
4090 |
4090 |
5840 |
5097 |
92 |
3040 |
4260 |
4260 |
6080 |
5326 |
95 |
3230 |
4510 |
4510 |
6440 |
5679 |
97 |
3340 |
4680 |
4680 |
6690 |
5920 |
100 |
3530 |
4940 |
4940 |
7060 |
6292 |
102 |
3660 |
5120 |
5120 |
7320 |
6546 |
105 |
3850 |
5390 |
5390 |
7700 |
6937 |
107 |
3980 |
5570 |
5570 |
7960 |
7204 |
111 |
4250 |
5940 |
5940 |
8480 |
7752 |
114 |
4440 |
6230 |
6230 |
8890 |
8177 |
117 |
4650 |
6510 |
6510 |
9300 |
8613 |
120 |
4850 |
6810 |
6810 |
9720 |
9060 |
122 |
5000 |
7000 |
7000 |
9990 |
9360 |
124 |
5140 |
7200 |
7200 |
10280 |
9675 |
127 |
5350 |
7490 |
7490 |
10710 |
10148 |
130 |
5570 |
7800 |
7800 |
11140 |
10635 |
132 |
5720 |
8000 |
8000 |
11420 |
10965 |
137 |
6080 |
8510 |
8510 |
12160 |
11810 |
142 |
6450 |
9030 |
9030 |
12910 |
12690 |
147 |
6840 |
9560 |
9560 |
13660 |
13600 |
152 |
7220 |
10100 |
10100 |
14430 |
14500 |
157 |
7600 |
10640 |
10640 |
15200 |
15520 |
162 |
7990 |
11180 |
11180 |
15980 |
16530 |
Marine anchor chain in factory:
IACS Certificates:
