Single Bitt Bollard

Single Bitt Bollard

Application: Mooring Single bitt bollard is usually designed for small ships and vessels,it’s common material is cast steel,also sometimes stainless steel.It has different capacities ,from 20T to 200T. there are several different material , Cast steel, cast iron, cast SG iron , the safe factor of bollard is 3 time. The face angle of cable is -45 to 45 (vertical), 0 to 1800 (horizontal) .Besides,we can provide you bollard according to your specific requirements.If you are interested in any of our products,please feel free to contact us.

Features:

Model Type:Single Bitt Bollard

Material: Casting Steel

Certificates: CCS,ABS,BV,LR,NK,RINA,etc.

Drawing of Single Bitt Bollard:

Capacity(tonnes)	Type	A	B	C	D	E	Bolts No.
20	SBD20	400	660	290	260	65	4
30	SBD30	400	660	290	260	65	4
50	SBD50	400	600	200	300	70	4
75	SBD75	440	700	340	330	85	4
100	SBD100	540	900	365	350	95	8
150	SBD150	610	900	340	420	120	8
200	SBD200	680	900	350	480	120	8

Mooring Bollard in Factory:
