Shafting Intermediate Bearing


Shafting Intermediate Bearing

Shafting Intermediate Bearing



Application

The shafting intermediate bearing is suitable for inland water vessels.This type of intermediate bearing is recommended for small and medium vessels in land water. There are four types A, B, C and D. Type A and type B are gliding intermediate bearing; and type C and type D are rolling intermediate bearing.

Advantages and Features

1. Compact structure, high quality;

2. Excellent performance, high security;

3. Working steadily and smoothly;

4. Easy installation, easy maintenance;

5. Corrosion resistance, long lifespan;

6. Reliable service, exquisite appearance;

7. Can be customized according to your requirements.

Drawing Of Product and Main Technical Parameters

Type A



Type B


JT4175 B gliding intermediate bearing

Model D A A1 B B1 B2 H H1 d Weight (kg)
B60 60 280 330 60 110 178 130 230 21 32
B70 70 290 340 70 120 180 135 242 21 35
B80 80 300 350 70 120 190 140 252 21 38
B90 90 330 380 80 130 210 150 272 21 46
B100 100 340 400 90 150 220 160 282 25 55
B110 110 350 410 100 160 240 180 308 25 57
B120 120 350 410 100 160 240 180 308 25 60
B140 140 405 470 116 180 275 198 340 32 73

Type C



JT4175 C rolling intermediate bearing

Model D D1 H H1 H2 A A1 B B1 d Weight (kg)
13514 70 140 95 224 30 270 310 70 128 21 19
13516 80 160 105 243 30 290 330 80 138 21 26
13518 90 180 120 270 35 320 360 90 148 21 30
13520 100 200 130 290 35 350 390 100 158 21 38
13522 110 215 137.5 310 40 370 420 110 178 25 46
13525 125 250 165 360 45 420 470 130 198 25 59

Type D




D JQ/CS 16 rolling intermediate bearing

Model D D1 L L1 B B1 H h d H1 Weight (kg)
3253122 110 180 386 326 170 110 150 35 20 330 30
3253123 115 200 406 346 180 120 160 35 20 345 35
3253125 125 210 430 360 190 120 165 40 26 360 43
3253127 135 225 446 376 200 130 175 40 26 380 53
3253128 140 240 476 396 210 130 180 45 26 400 66
3253130 150 250 486 406 220 140 190 45 32 415 80
3253132 160 280 516 436 220 140 205 50 32 445 95
3253134 170 290 540 450 240 150 210 50 38 460 112
3253136 180 310 560 470 240 150 220 55 38 485 130
3253140 200 340 590 500 250 160 240 55 38 530 150
3253144 220 360 640 530 270 160 260 60 44 570 175
3253148 240 400 680 570 290 180 280 60 44 610 200
3253152 260 420 720 600 300 180 300 65 50 650 230
3253156 280 460 760 640 310 190 320 65 50 690 260
3253160 300 480 800 670 320 190 340 70 58 730 290
3253164 320 520 840 710 330 200 360 70 58 770 340
Note: The sizes of  these table are for reference only. The product can be manufactured according to your request.


Certificates

The products approved by CCS, BV, ABS, RINA, NK, DNV-GL,etc.
