CB*3333 Stern Shaft Lubrication Oil Tank


CB*3333 Stern Shaft Lubrication Oil Tank

CB*3333 Stern Shaft Lubrication Oil Tank



Application

This Type of oil tanks have above 30L can be equipped with a low oil alarm devie.The oil tank is used to store oil source. CB*3333 Stern Shaft Lubrication Oil Tank is a type of marine tank used to store lubricating oil for the vessel's propulsion system. This tank is typically located in the engine room and is used to supply oil to the stern tube and associated lubrication system. The lubricating oil is essential for reducing friction and wear between the propeller shaft and the stern tube bearings. The CB*3333 Stern Shaft Lubrication Oil Tank is designed to hold an adequate supply of oil to ensure that the system is properly lubricated and that the bearings are adequately protected.

Advantages and Features

1. Compact structure, high quality;

2. Excellent performance, high security;

3. Working steadily and smoothly;

4. Easy installation, easy maintenance;

5. Corrosion resistance, long lifespan;

6. Reliable service, exquisite appearance;

7. Can be customized according to your requirements.

Remarks

1.This system doesn't need a oil pump.

2.The oil level won't be lower than the deep load.

3.It is applicable to vessels whose sea gauge is no longer deeper than 10m.

3.The lubrication oil brand should be the same as the main unit.

4.We can modify the technical parameters, according to your special requirements.

Technical Parameters
Model Capacity A B H H1 d Applicable stern shaft diameter Weight(kg)
one shaft with one oiltank two shafts with one oil tank
15CB*3333 15 245 370 630 360 15 ≥70≤120 <70 10
30GB*3333 30 245 520 730 460 15 >120≤170 ≥70≤120 15
50CB*3333 50 285 670 730 460 20 >170 18 /
Drawing of Product
