N2 Inerting Device - Fire Fighting System - Hi-sea

N2 Inerting Device


N2 Inerting Device


Description:

This device consist of nitrogen cylinder group, cylinder head valve, check valve, safety valve, gas collecting tube, pressure reducing valve, flow separating pipe, pressure reducing control box, high pressure pipe fittings, low pressure pipe fittings, pressure gauge, etc. The typical assembly forms of cylinder include single row, double rows with two-side disassembly, double row with single-side disassembly, three rows with single-side disassembly.

Product Detail:

Model
Capacity(L)
Nominal pressure(MPa)
Medium
Working temperature
First level of outlet pressure(MPa)
Second level of outlet pressure(MPa)
Operating mode
YND40
40 20 N2
-20℃~+55℃
0.7
0.01~0.2
manual
YND50
50 15
YND68
68

Drawing of N2 Inerting Device:
