Marine Steel Parallel Flange Channels

Marine Steel Parallel Flange Channels

Application:

Parallel steel channels are long steel products with a solid U-shaped metal section produced with different steel grades. The marine steel parallel flange channels are one kind of hot rolled steel channel. They are showed by height, width and thickness, for example, 120×53×5.5. We can provide with the dimensions, shape and weight of the steel channels according to Chinese standard GB/T 706-2008. The marine steel parallel flange channels have good weld ability, excellent riveting and comprehensive mechanical properties. We can provide high quality products. If you have any specific requirements or you are interested in our marine steel parallel flange channels, welcome to contact us.

Features:

• Manufactured in line with GB/T 706-2008

• Made of high quality steel

• Full selections of steel grades

• Standard dimensions with marginal tolerances

• Well-shaped

Dimensions:

Model

Sectional Dimension

Sectional Area (cm2)

Theoretical Weight (kg/m)

h

b

d

t

r

r1

5

50

37

4.5

7.0

7.0

3.5

6.928

5.438

6.3

63

40

4.8

7.5

7.5

3.8

8.451

6.634

6.5

65

40

4.3

7.5

7.5

3.8

8.547

6.709

8

80

43

5.0

8.0

8.0

4.0

10.248

8.045

10

100

48

5.3

8.5

8.5

4.2

12.748

10.007

12

120

53

5.5

9.0

9.0

4.5

15.362

12.059

12.6

126

53

5.5

9.0

9.0

4.5

15.692

12.318

14a

140

58

6.0

9.5

9.5

4.8

18.516

14.535

14b

60

8.0

21.316

16.733

16a

160

63

6.5

10.0

10.0

5.0

21.962

17.24

16b

65

8.5

25.162

19.752

18a

180

68

7.0

10.5

10.5

5.2

25.699

20.174

18b

70

9.0

29.299

23.000

20a

200

73

7.0

11.0

11.0

5.5

28.837

22.637

20b

75

9.0

32.837

25.777

22a

220

77

7.0

11.5

11.5

5.8

31.846

24.999

22b

79

9.0

36.246

28.453

24a

240

78

7.0

12.0

12.0

6.0

34.217

26.860

24b

80

9.0

39.017

30.628

24c

82

11.0

43.817

34.396

25a

250

78

7.0

34.917

27.410

25b

80

9.0

39.917

31.335

25c

82

11.0

44.917

35.260

27a

270

82

7.5

12.5

12.5

6.2

39.284

30.838

27b

84

9.5

44.684

35.077

27c

86

11.5

50.084

39.316

28a

280

82

7.5

40.034

31.427

28b

84

9.5

45.634

35.823

28c

86

11.5

51.234

40.219

30a

300

85

7.5

13.5

13.5

6.8

43.902

34.463

30b

87

9.5

49.902

39.173

30c

89

11.5

55.902

43.883

32a

320

88

8.0

14.0

14.0

7.0

48.513

38.083

32b

90

10.0

54.913

43.107

32c

92

12.0

61.313

48.131

36a

360

96

9.0

16.0

16.0

8.0

60.910

47.814

36b

98

11.0

68.110

53.466

36c

100

13.0

75.310

59.118

40a

400

100

10.5

18.0

18.0

9.0

75.068

58.928

40b

102

12.5

83.038

65.208

40c

104

14.5

91.068

71.488

Note

The data of r, r1 will not be as terms of delivery.

Profile of Marine Steel Parallel Flange Channels:

h--height

b--width

d--web thickness

t--average flange thickness

Z0--the interval between YY and Y1Y1

Angle steel in factory:
