JIS F7311 Marine Cast Steel Globe Valve

JIS F7311 Marine Cast Steel Globe Valve

1. Application

Marine ball valves with materials compatible with marine and offshore environments.

2.Material

(1) -  Body : Cast Steel

(2) - Seat : Stainless Steel

(3)  - Disc : Stainless Steel

(4)  - Stem : Stainless Steel

3.Nominal Diameter & Pressure

Diameter: ND50~ND300

Pressure: 5K

4.Feature

(1) We provide OEM service, accept customer label, develop the product with your drawings or samples.

(2) Well-selected materials, meet with domestic and foreign standards, reasonable structure.

5.Main Size List

IMPA Code	Model	L	D	C	No.	h	t	H	D2
	F7311 5K050	210	130	105	4	15	14	270	160
	F7311 5K065	250	155	130	4	15	14	300	180
	F7311 5K080	280	180	145	4	19	14	310	180
	F7311 5K100	340	200	165	8	19	16	360	224
	F7311 5K125	410	235	200	8	19	16	390	250
	F7311 5K150	480	265	230	8	19	18	445	280
	F7311 5K200	570	320	280	8	23	20	530	315
750401	F7311 5K250	740	385	345	12	23	22	791	355
750402	F7311 5K300	840	430	390	12	23	22	929	400

6.IACS Certificate:ABS, BV, CCS, LR, RINA
