JIS F -2006 Open Chock

JIS F -2006 Open Chock

Application: JIS F - 2006 Open chock has two types: JIS F - 2006 type FC and JIS F - 2006 type SC.Both are deck mounted and are with good quality.It can control the position of the rope and meanwhile protect the rope from breaking.Besides,we Hi-sea can also provide you other marine equipment,so if you have any questions,please contact us via email or phone.

Features:

Model Type: JIS F -2006 Open Chock Type FC/SC

Material: Casting Steel/Casting Iron

Certificates: CCS,ABS,BV,LR,NK,RINA,etc.

Standard: JIS F 2006

Drawing of JIS F -2006 Open Chock Type FC:

Nominal

size

L

(mm)

L1 a B b B1 H h h1 l l1 l2 l3 R R1 r r1 r2 r3 t t1 t2

Calculated

mass

(kg)

150 400 29 80 52 75 85 25 28 60 60 65 45 20 170 37.5 10 95 32 15 25 25 11.5
200 500 34 110 60.5 110 105 30 35 65 80 85 60 22 210 46.5 12 117 44 20 30 33 19.0
250 600 42 130 73 120 125 35 42 70 110 105 70 24 220 55.5 14 139 52 22 32 40 31.5
300 700 50 150 89.5 140 145 40 49 75 140 125 80 32 220 63.5 18 163 60 25 35 45 47.0
350 800 57 170 100 150 160 45 55 80 165 145 92.5 34 280 70 20 190 70 28 38 48 68.0
390 900 65 190 112 160 175 50 62 95 190 160 100 34 330 77.5 20 215 80 30 40 52 91.0
420 1000 79 210 131 190 195 55 67 100 210 190 105 34 380 86.5 22 240 90 32 42 55 130

Drawing of JIS F -2006 Open Chock Type SC:

Norminal

size

L

(mm)

L1 B B1 H h h1 l l1 R R1 r r1 r2 r3 r4 t t1 S

Calculated

Mass

(kg)

150 280 80 80 90 28 8 60 45 40 160 35 10 100 32 40 12 20 6 10.7
200 380 110 110 116 35 8 84 58 55 200 46 12 136 44 55 16 24 6 18.1
250 460 130 130 136 42 10 114 68 65 250 54 14 160 52 65 18 26 6 29.2
300 540 150 150 160 49 10 140 80 75 300 62 18 180 60 75 20 28 8 44.0
350 620 170 170 180 55 12 170 90 85 350 70 20 205 70 85 22 30 8 64.0
400 700 200 200 200 63 12 200 100 100 400 80 20 230 83 100 25 33 8 98.0

JIS F-2006 Open Chock in Factory:

JIS F -2006 Open Chock
