FA-SPYCY Shipboard Power Cable

FA-SPYCY Shipboard Power Cable

FA-SPYCY 0.6/1kV:
Flame-Retardant, Single core, EP rubber insulated, PVC sheathed, Steel wire braided,PVC Cover Shipboard Power cable.


Cable Construction:
1.Conductor:Tinned Annealed Stranded Copper,Class2 according to IEC 60228
.Insulation:85°C (EPR),Ethylene Propylene Rubber
3.Filler:Non-Hygroscopic Material
4.Sheath:(PVC),Polyvinyl Chloride
5.Armor:Galvanized Steel Wire Braid
6.Protective cover:(PVC),Polyvinyl Chloride

Standard:
JIS C 3410-2010 IEC 60092-350 IEC 60332-1 IEC 60332-3 Cat.AF(for FA-type)


Applications:
For fixed installations on ships and offshore-units in all locations.


(FA-)SPYCY, SPYCBY Specifications:

Conductor Thick. of insulation Thick. of bedding Dia. over bedding Dia. of armor (FA-) SPYCY, SPYCBY
Size Construction O.D Thick.of Sheath Nominal overall dia. Tolerance Cable weight (Approx.)
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

1.5

7/0.53

1.59

1.0

1.0

5.9

0.3

0.8

9.0

0.4

135

2.5

7/0.67

2.01

1.0

1.0

6.3

0.3

0.8

9.4

0.4

150

4

7/0.85

2.55

1.0

1.0

6.9

0.3

0.8

10.0

0.4

175

6

7/1.04

3.12

1.0

1.0

7.4

0.3

0.8

10.5

0.4

205

10

7/1.35

4.05

1.0

1.1

8.6

0.3

0.8

11.7

0.5

270

16

7/1.70

5.1

1.0

1.1

9.6

0.3

0.9

12.9

0.5

350

25

7/2.14

6.42

1.2

1.2

11.5

0.3

0.9

14.8

0.6

485

35

7/2.52

7.56

1.2

1.2

12.7

0.3

1.0

16.2

0.6

605

50

19/1.78

8.9

1.4

1.3

14.6

0.3

1.0

18.1

0.7

775

70

19/2.14

10.7

1.6

1.4

17.2

0.3

1.1

20.9

0.8

1060

95

19/2.52

12.6

1.6

1.5

19.3

0.3

1.1

23.0

0.9

1360

120

37/2.03

14.2

1.6

1.5

20.9

0.3

1.2

24.8

1.0

1650

150

37/2.25

15.8

1.8

1.6

23.1

0.3

1.2

27.0

1.1

1980

185

37/2.52

17.6

2.0

1.7

25.5

0.3

1.3

29.6

1.2

2420

240

61/2.25

20.3

2.2

1.8

28.8

0.3

1.4

33.1

1.3

3110

300

61/2.52

22..7

2.4

1.9

31.8

0.4

1.4

36.6

1.5

3910
