Electric Combined Windlass


Electric Combined Windlass

Electric Combined Windlass



Advantages

HI-SEA marine's line of el-combined windlass offer all kinds of models to meet your anchor application. According to power type, there are electric windlass, diesel engine eindlass, hydraulic windlass. It can be equipped with warping head. The brakes are easily adjustable, and all transfer of external forces to the deck construction is for the foundation bolts.

Material

Cast steel, 316L stainless steel.

Advantages and Features

1. Contract structure, high quality;

2. Local control and remote control;

3. Easy installation, low maintenance;

4. Corrosion resistance, long lifespan;

5. Excellent operation, exquisite appearance;

6. Low power consumption, high efficiency;

7. Reliable service, high security;

8. Can be customized accorfing to your requirements.

Main Specifications
Main Technical Data Of Winch
Chain Dia. Working Load Working Speed Mooring Pull Mooring Speed Motor Power
mm KN m/min KN m/min kW
14/16/17.5 8.3/10.9/13.0 ≥9 8 ≥12 4.3/1.7
19/20.5/22 15.3/17.9/20.6 ≥9 15 ≥12 8.5/3.5
24/26 24.5/28.7 ≥9 20 ≥12 8.5/3.5
28/30 33.3/38.3 ≥9 30 ≥12 11/11/7.5
32/34/36 43.5/49.1/55.1 ≥9 40 ≥12 16/16/11
38/40/42 61.4/68.0/75.0 ≥9 50 ≥12 22/22/16
44/46/48 82.3/89.9/97.9 ≥9 60 ≥12 30/30/22
50/52/54 106.3/114.9/132.9 ≥9 60 ≥12 30/30/22
56/58/60 133.2/143.0/153.0 ≥9 80 ≥12 45/45/30

Drawing Of Electric Combined Windlass




Certificates

The products approved by CCS,ABS,DNV-GL,BV,RINA,LR,NK,etc.
