Double Gypsy Wheel Windlass

Double Gypsy Wheel Windlass

Double Gypsy Wheel Windlass

Application
Windlass is installed in the ship's stern main deck used for ship setting sailing and anchor mooring.We supply various types of marine windlass,such as symmetrical windlass,single electric windlass,single hydraulic windlass,symmetrical hy-combined windlass,etc.The follow technical parameters are not fixed,they can be designed specially,according to customers' requirements.

Main Specifications
1.Chain cable diameter:19mm to 73mm
2.Nominal pull:15.3kN to 226.5kN
3.Anchor depth:82.5m
4.Nominal drum load;15kN to 160kN
5.Wire rope diameter:13mm to 32mm
Main Technical Data Of Windlass
Chain Dia. Working Load Supporting Load Working Speed Warping Load Motor Power
mm KN KN m/min KN kW
70/73 208.3/226.5 1160/1254 ≥9 100 75
76/78 245.5/258.6 1350/1416 ≥9 125 90
81/84 311.7/335.2 2171/2320 ≥9 140 110
87/90 359.5/384.8 2473/2629 ≥9 150 120
92/95 402.0/428.7 2735/2898 ≥9 200 130
97/100 446.9/475.0 2995/3162 ≥9 250 150
105/107 523.7/543.8 3612/3750 ≥9 300 180
112/114 595.8/617.3 4109/4228 ≥9 350 200
Drawing of Single Electric Windlass

Certificates
The products approved by CCS,ABS,DNV-GL,BV,RINA,NK,etc.
