CDD-300 Marine Electric Horn

CDD-300 Marine Electric Horn

Description:

CDD-300 multifunctional marine electronic spiral channel electric flute is a new generation of patented marine sound signal equipment developed and produced by our factory. It has the characteristics of diverse functions, high power, clear sound and long sound transmission distance. This product has a maximum output power of 300 watts, an effective sound transmission distance of more than 1000 meters, and a maximum sound pressure of more than 131 decibels, filling the gap of similar domestic products. The generation of tones is programmed by single-chip software, the circuit is simple, and the frequency is stable. The accompanying 300W speaker adopts an involute spiral design, which is waterproof, dustproof, and UV resistant. It can adapt to a variety of complex outdoor operating environments, and the protection level is IP56. The loudspeaker is filled with imported magnetic fluid to protect the voice coil, which overcomes the defect that the previous electroacoustic loudspeaker is easy to burn out, thereby greatly increasing the service life of the loudspeaker. This product is widely used in water transportation, docks and related places.

Certificate & Standard

Certificate: CCS

Standard: Fishing Vessel Inspection Bureau of the People's Republic of China, etc.

Technical parameter:

Rated power: 300W

Working voltage: DC24V (±10%)

Frequency: 400～700HZ

Harmonic distortion: ≤5%

Effective transmission distance: 1000M

Output sound pressure: ≥131dB

Operating temperature: -30℃～+55℃

Protection class: IP56

Random speaker Dimensions: 730×240×435mm; Weight: 11kg

Dimensions of the host: 200×195×108mm; Weight: 2.2kg

Total weight: 1.8Kg

Whistle frequency: 500Hz

Applicable captain: 25m≤L＜75m

Effective sound transmission distance: whistle 1 nautical mile (1852 meters) / shout loudspeaker 700 meters

Detail of CDD-300 marine electronic whistle:

Drawing of CDD-300 marine electronic whistle:

Picture of CDD-300 marine electronic whistle:
