CB T3591-94 Oil Tanker Gate Valve

CB T3591-94 Oil Tanker Gate Valve

1. Application

CB T3591-94 Oil Tanker Gate Valve with excellent quality can apply to repair ships and shipbuilding, it can be used in sea water, fresh water and oil.

2. Material

(1) body & cover: nodular cast iron

(2) disc: cast steel

(3) stem & nut: aluminum bronze

(4) seal ring: stainless steel

The material of this product can be made to order, for example:cast iron, stainless steel 304, stainless steel 316L etc.
3. Technical Data

(1) nominal pressure(MPa): 1.0
(2) nominal diameter(mm): 80~400

4. Features

(1) Flexible customization according to business requirements.

(2) Excellent quality and beautiful shape.

5. Dimensions

Type A & Type B

DN	Structure dimension			flange					bolt
	L	H		D	D1	D2	d0	b	Th.	n
		A	B
80	220	440	375	170	138	118	15	16	M14	8
100	230	470	400	190	158	138
125	245	515	445	215	183	164				10
150	260	560	470	240	208	190				12
200	290	660	555	310	273	250	17	21	M16
250	335	780	655	380	336	310	22	24	M20	14
300	360	885	745	435	391	364		26		16
350	400	990	850	485	414	414				18
400	450	1100	960	545	496	466	26	28	M24

Type AS & Type BS

DN	Structure dimension			flange					bolt
	L	H		D	D1	D2	d0	b	Th.	n
		AS	BS
80	203	440	375	200	160	133	18	22	M16	8
100	229	470	400	220	180	158		24
125	254	515	445	250	210	184		26
150	267	560	470	285	240	212	22		M20
200	292	660	555	340	295	268
250	330	780	655	395	350	320		28		12
300	356	885	745	445	400	370
350	381	990	850	505	460	430		30		16
400	406	1100	960	565	515	482	26	32	M24

6. IACS Certificate: DNV, KR, BV, CCS, LR, NK, ABS, RINA.
