Marine Windlass


Bow Windlass

Marine Windlass



Application

HI-SAE Marine windlass is ship machinery for anchoring, anchor drop, also used as mooring on boad. According to power type, there are electric windlass, hydraulic windlass and diesel engine windlass. According to the arrangement, there are single gypsy wheel windlass, double gypsy wheels windlass and combined windlass. It can be equipped with warping head.

Material

Cast steel, 316L stainless steel.

Advantages and Features

1. Contract structure, high quality;

2. Local control and remote control;

3. Easy installation, low maintenance;

4. Corrosion resistance, long lifespan;

5. Excellent operation, exquisite appearance;

6. Low power consumption, high efficiency;

7. Reliable service, high security;

8. Can be customized accorfing to your requirements.

Main Specifications
Main Technical Data Of Windlass
Chain Dia. Working Load Supporting Load Working Speed Warping Load Motor Power
mm KN KN m/min KN kW
14/16/17.5 8.3/10.9/13.0 51/67/80 ≥9 8 5.5
19/20.5/22 15.3/17.9/20.6 95/110/126 ≥9 10 7.5
24/26 24.5/28.7 149/175 ≥9 20 11
28/30 33.3/38.3 202/231 ≥9 30 15
32/34/36 43.5/49.1/55.1 261/294/329 ≥9 30 22
38/40/42 61.4/68.0/75.0 365/402/442 ≥9 40 30
44/46/48 82.3/89.9/97.9 483/526/570 ≥9 50 37
50/52/54 106.3/114.9/132.9 617/664/713 ≥9 50 45
Drawing of Products



Certificates

The products approved by CCS,ABS,DNV-GL,BV,RINA,NK,etc.
