ASME E9015-G Welding Electrode

ASME E9015-G Welding Electrode

ASME E9015-G Welding Electrode

1. Application

ASME E9015-G Welding Electrode is a 590Mpa non-crack steel used in the ultra-low hydrogen sodium type Marine electrode, it has a good notch impact toughness and crack resistance, and adopts dc reverse connection, which can be used for full position welding.It is usually used to weld the pressure vessels, Bridges, power stations and ocean engineering structures of ordinary strength steel.

2. Standard

(1) GBT5118 E6015-G

(2) ASWE SFA-5.5 E9015-G

3. Typical Chemical Composition


C

Mn

Si

Mo

Ni

S

P

norm

0.10

1.00

0.80

0.1-0.4

0.60

0.015

0.02

e.g.

0.072

1.51

0.35

0.24

1.10

0.008

0.014

4. Mechanical Property of Deposited Metal


ReH (MPa)

Rm (MPa)

A5 (%)

KV2 (J)

norm

500

610-770

18

50

e.g.

550

650

25

95

5. Reference Current

Welding Diameter

2.5

3.2

4.0

5.0

Welding length

300

350

400

400

welding current

60-90

80-120

130-170

170-210

6. Certificate: CCS, DNV.GL, KR, LR, NK, BV, ABS.
